Home Biking Bike Tires CeramicSpeed BB ALPHA BB86 SRAM DUB Road Bottom Bracket, Press-Fit Ceramic Bearings with Lifetime Warranty
CeramicSpeed BB ALPHA BB86 SRAM DUB Road Bottom Bracket, Press-Fit Ceramic Bearings with Lifetime Warranty
1,869
Default variant
AVAILABILITY: In stock (6 items)
PRODUCT INFORMATION
Features
Specification
CUSTOMER REVIEWS
PRODUCT INFORMATION
The CeramicSpeed BB ALPHA for BB86 SRAM DUB Road is a ceramic bottom bracket built to outlast your frame. Grade-3 silicon nitride ceramic balls run in hardened stainless steel races for very low friction, and custom seals with stainless-backed covers give up to 500% better moisture protection, useful when sweat, dust and the odd wash-down get at your bike.
This version pairs a SRAM DUB crankset (28.99 mm axle) with a press-fit 41 mm bore that is 86 mm wide, known as BB86. Lighter cups and a simplified spacer tube make installation quicker, and every BB ALPHA carries CeramicSpeed's lifetime warranty.
Features
Feature What it does for you Hardened stainless races Corrosion resistant races hand-built with grade-3 silicon nitride ceramic balls. Custom seals Light contact seals with up to 500% better moisture protection, per CeramicSpeed. Low friction Signature CeramicSpeed low drag every pedal stroke. Lighter cups Simplified spacer tube and cups, about 10% lighter than the previous generation. Lifetime warranty Every BB ALPHA is covered by CeramicSpeed's lifetime warranty.
Specification
Shell standard BB86 press-fit, 41 mm bore, 86 mm wide Crank axle SRAM DUB 28.99 mm Bearings Grade-3 silicon nitride balls, hardened stainless races Weight 204 g (CeramicSpeed listed) Warranty Lifetime (CeramicSpeed) In the box BB ALPHA, UFO TECH All Round bearing grease 5 ml, decal
Shipping and package Package size (L x W x H) 12 x 10 x 6 cm Shipping weight 0.3 kg
Frequently Asked Questions
Will it fit my frame and crank?
▼
It fits BB86 press-fit frames (41 mm bore, 86 mm wide) with SRAM DUB road cranks (28.99 mm axle). Check your frame's bottom bracket standard and crank axle before ordering.
Is it hard to install?
▼
It uses standard bottom bracket tools. The simplified spacer tube and cups make fitting quicker than earlier CeramicSpeed models; have a bike shop fit it if you are unsure.
What warranty does it have?
▼
CeramicSpeed covers all BB ALPHA models with a lifetime warranty.
